Full Port Ball Valve, ANSI 150 LBS, L-port and T-port, flanged ends, with locking handle.
ISO 9002
The flange ends conform to ASME B 16.5
Full Port
ANSI 150
15% glass fiberfill PTFE reinforced seat
PTFE seal & packing
Blow out proof stem
L-port and T-port
All valves tested and inspected to API-598
Item | Parts | Material |
1 | Body | ASTM A351-CF8M |
2 | Flanged for Valve | ASTM A351-CF8M |
3 | Ball & Stem | ASTM A351-CF8M |
4 | Ball Seat | RTFE |
5 | Joint Gasket | PTFE |
6 | Gasket | PTFE |
7 | Stem Packing | PTFE |
8 | Gland | ASTM A351-CF8 |
9 | Cover | ASTM A351-CF8M |
10 | Bolt | SS 304 S45C |
11 | Stopper | SS 304 |
12 | C Retainer Ring | S45C |
13 | Handle | FCD |
14 | Bolt | SS 304 S45C |
15 | Nut | SS 304 S45C |
16 | Stud | SS 304 S45C |
17 | Sleeve | PTFE |
